Replacing My Floor Outlet Receptacle

2 years ago
31

Electric Pro Academy - Real skills to make real money.

Synopsis:
Some DIYers and handymen can bypass key safety measures without realizing (and some realize it but do it anyway!). A pretty frequent culprit of neglect is floor-mounted outlet receptacles. While it might seem like the same old boxes and devices can fit in the floor just as easily as they fit in the wall, the key difference is weight-ratings. Floor-mounted receptacles are specifically designed to withstand heavy load, which protects inhabitants from shock and arc hazards.

Joel wears his husband, dad, and electrician hats in this video as he upgrades an out-of-code floor-mounted receptacle with a proper floor-rated outlet receptacle in his own home. Laced within the technical instruction are recommendations and points of professionalism employed daily by Jefferson Electric masters, journeymen, & apprentices.

If the instruction in this video is unclear or skew to what you are searching for, feel free to comment below for additional assistance. Got a question or ideas for a future video? Leave a comment below and submit your idea here: https://forms.clickup.com/f/23xa9-70/MU8E4HBGPNY3NXVQA3

Thank you for watching; we value your feedback and monitor this channel daily.

Products We’d Recommend:
*EPRO endorses pro-level tools & materials, and receives a small commission for purchases through our links through Amazon & other affiliate programs. We’d be happy to recommend more cost-effective products for DIYers and low-frequency users if you engage with us in the comment section!
[] Bryant Electric Floor Box Kit: https://amzn.to/34lD0GG
[] Dewalt 20V Max XR Brushless Oscillator (DCS356): https://amzn.to/3mYfZ2O
[] Dewalt 20V Max XR Brushless Sawzall (DCS367): https://amzn.to/31oocG0
[] Dewalt 20 Max VR Brushless Hammer Drill (DCD999B): https://amzn.to/3FXUAhL
[] Irwin 3/4" Self-Feeding Wood Drill Bit: https://amzn.to/3zoiD77
[] Non-Contact Voltage Detector: https://amzn.to/3mVhRtr
[] Klein Tools GFCI Receptacle Tester: https://amzn.to/32LUJGN
[] Scotch Linerless Black Electrical Tape: https://amzn.to/3ERXkvN
[] Klein Tools Insulated Screwdriver Set: https://amzn.to/3qMkjU6
[] ATG Maxiflex Nitrile Gloves: https://www.homedepot.com/p/ATG-MaxiFlex-Men-s-Large-Nitrile-Ultimate-Gloves-in-Gray-34-874T-LVPD72/313135021
[] HDX Eye Protection: https://www.homedepot.com/p/HDX-Indoor-Safety-Clear-Glasses-VS-9300-clear/309028882
[] Milwaukee Folding Rule (Inside Reading): https://www.homedepot.com/p/Milwaukee-78-in-Composite-Folding-Ruler-48-22-3801/206414727

National Electrical Code (NEC) referenced in this video:
Free Access Here: https://www.nfpa.org/codes-and-standards/all-codes-and-standards/list-of-codes-and-standards/detail?code=70
[] Tamper-Resistant Receptacles [NEC 406.4(D)(5)]
[] Floor-Rated Electrical Boxes [NEC 314.27(B)]

Outline:
0:00 - Introduction
1:11 - Tools & Prep
1:57 - Removing Old Outlet Receptacle & Box
5:42 - Planning New Receptacle Location
11:50 - Cutting Flooring For New Receptacle
18:27 - Mounting New Floor-Rated Electrical Box
22:19 - Wiring New Electrical Box
24:22 - Mounting Receptacle & Floor Plate
31:30 - Minor Equipment Failure
32:32 - Final Test & Code
