6” Exhaust Parts
Preparing to hook up a 6" exhaust system. This is the kind of thing that I love having a FDM printer for. Not Marvel figures but useful items such as these exhaust parts. The flange is 150mm dia which is ~2,4 mm smaller than the 6" dia exhaust ducting.
3
views
Outer Exhaust Port
This is part of a 6" exhaust port. The near side is where the exhaust ducts connects .. this is on the far side that clamps to the near duct and sandwiches the screen in between.
1
view
Domes for a tank
I scratchbuilt this O scale Oil Tank some years back and over time I managed to knock off the dome and vent tube I had installed. I 3D printed a new dome and access hatch. To hold them in place while the cement sets and ensure the flange fits tight against the body of the tank I made a simple clamp/jig.
2
views
Using Rare Earth Magnets to secure structures on your layout
This is the best way I have found to secure various structures to a layout or diorama. The structures can be easily removed but are very secure as Rare Earth magnets are so strong. I am currently using 8mm x 2mm magnets I picked up at Harbor Freight for $3 for 10ea. I like these so much that I have ordered additional Rare Earth magnets from Amazon in smaller sizes.
4
views
1
comment
No 223 90deg jig
This was done for fun .. playing around to see how best to make a gluing jig for Evergreen tubing and a small printed fitting. No real reason .. just exploring CAD
1
view
Vetero Stain Stabilizer
Vetero Stains are great. They come in glass bottles that may tip over if someone such as myself manages to hit it. I am really good at doing this sort of thing. To alleviate this I created these stabilizers. To knock over a bottle in the stabilizer would require a lot of effort!
STL download: https://www.micromimesis.com/product/vetero-stain-stabilizer/
Jason Jensen Trains: https://www.youtube.com/channel/UCwtCiywyxpf5ed785KbAAQA
Vetero Stains: http://www.besttrains.com/vetero.html
1
view
1:24 Beer Bottles and Crates
an update on my 1:24 Beer Bottles and Crates. I talk about what I did wrong, what I might have done right and what I want to do to tweak the prints.
53
views
1:24 Beer Crates and Bottles V3 Update
Completely re-worked the 1:24 Beer Bottle crates so the bottles fit much better. I also made a version with an open floor which allows a set of bottles to be inserted w/floor into the crate .. which allows painting the bottles and the crate separately.
25
views
1:24 Beer Crates - Test Run
Printed on my Prusa SL1S resin printer. A test printing with one crate printed horizontal with heavy supports only on the bottom and the other at 45° with heavy supports on the bottom and medium supports on the one side.
Conclusion is too much support scaring on the 45° print. The other one is mostly ok .. but think it needs additional Light supports around the perimeter of the bottom.
These were printed at 0.05 mm layers. I may try at 0.025 layers to see the difference if any.
44
views
1:24 Beer Crates - First Test Run
Printed on my Prusa SL1S resin printer. A test printing with one crate printed horizontal with heavy supports only on the bottom and the other at 45° with heavy supports on the bottom and medium supports on the one side.
Conclusion is too much support scaring on the 45° print. The other one is mostly ok .. but think it needs additional Light supports around the perimeter of the bottom.
These were printed at 0.05 mm layers. I may try at 0.025 layers to see the difference if any.
23
views
O scale Clever Models Cardstock Kit - Jukes Boat Storage
This is look at my version of a Clever Models Cardstock model - Jukes Boat Storage. I cover installing the model on my layout. This is not a SBS on the build but an overview of emplacing the model on my Deep River Railroad.
21
views
1
comment
Bob Smith Industries Bottle Stabilizers
I was concerned that I would knock over my bottles of super glue activator and remover so I created these 'stabilizers' to help prevent that. You can print your own as I made the STL files available on my MicroMimesis.com website store
https://www.micromimesis.com/product/bottle-stabilizer-bob-smith-industries-un-cure-1oz-28g/
https://www.micromimesis.com/product/bottle-stabilizer-bsi-insta-set-1oz/
19
views
Vetero Stabilizer
The bottles used for Vetero stain are great being glass flasks. The only downside is they are 'tippy'. To address this issue I created stabilizers to help prevent the bottles from being knocked over.
You can download the STL file from my MicroMimesis.com store for free
https://www.micromimesis.com/product/vetero-stain-stabilizer/
25
views
Stabilizers for Vetero weathering fluid or .. OH NO Jason Jensen !!
As clumsy as I am I am sure to tip over one of my bottles of Vetero weathering fluid. To help prevent that I made these stabilizers which should help stabilize, and prevent the bottles from tippling over. I have a download link at my Micromimesis.com store where you can download the STL file for these if you want to print them for yourself.
https://www.micromimesis.com/product/vetero-stain-stabilizer/
I printed my stabilizers in PLA. I suggest primering and painting for long term use
93
views
3
comments
Stabilizers for BSI de-Bonder and Accelerator bottles
I have had problems knocking over bottles of Super Glue, Paint, Accelerators and such. To help prevent this I created these stabilizers for Bob Smith Industries' de-Bonder and Accelerator
84
views
Evergreen Plastics Tubing Gauge Box
I want/need examples of all of the Evergreen Plastics tubing .. Square, Rectangular and Round handy to act as a gauge when needed in my modeling. I am calling this Version 3 Beta .. I .. think .. a few more tweaks and it will be good to go. This then is simply a status update for a work in progress.
3
views
Wall Greeble
A Greeble is detailing added to a larger object that makes it appear more complex.
I am working with Foggy Mountain Models to sell these.
https://foggymountainmodels.com/shop
1
view
O scale Deep River Railroad - 25 April 2021
Just a quick update showing where I need to put in a dock for barge traffic, the missing rowboat and Widget Supply Co. ... influenced by watching Jason Jensen videos I want to add an extension to the right side for a water tower. I also weathered the structure .. also influenced by Jason's videos.
2
views
1:24 Scale Dry Bulk Semi-Trailer 3D parts
Hopper Tees, aerator valves, 22-1/2° and 45° elbows for Evergreen No.225 tubing, 45° and 90° elbows for Evergreen No.228 tubing, 90° reducing elbow (No.228-No.225 Evergreen tubing) with valve, both No.228 and No.225 capping flanges. What you have are parts for a s scratch builder in 1:24 scale.
3
views
