FreeCAD Assembly 3 - How to Make Assemblies and Avoid Errors (Multiple Methods) |JOKO ENGINEERING|
In this video we cover how to make an assembly with external files, how to make an assembly with bodies internal to a single file, and how to avoid "Inconsistent Constraints" errors.
I have an open invitation for all to edit/add detail to the engine that has been started if anyone is looking to practice working with the A3 workbench. Feel free to edit/re-upload this (shoutouts welcome!) and we will see what a community can do with a vague engine model.
In addition to what is discussed in the video, inconsistent constraints may also appear if the constraints added are physically impossible to exist.
Download this model:
https://grabcad.com/library/freecad-a3-example-1
Official Documentation on this Workbench:
https://wiki.freecadweb.org/Assembly3_Workbench
RealThunder Branch Downloads:
https://github.com/realthunder/FreeCAD_assembly3/releases
0:00 - How to get Assembly 3 Workbench
1:35 - File Management of External Files
10:44 - Importing External Files To Assembly Using Link
12:10 - Establish Parts and Create Mates
14:13 - Degrees of Freedom and Avoiding Errors ("Inconsistent Constraints")
21:03 - What are elements? Demonstration of Editing Parts In an Assembly
26:56 - Quick Recap
28:05 - Example of Managing Assembly of Internal Bodies
42:04 - Quick Look at Documentation
FREE SolidWorks Certification Course
https://alison.com/course/solidworks-an-introduction-to-the-3d-editor
Idea for a video?
If there is music in this video, it is legally used.
-
