Setup Studio 5000 Produced Consumed Data | PLC Processor Communication

Communication between PLC program to PLC program is highly used for system integration so that all PLC programs communicate important data back & forth.

This process works for RSlogix 5000 or Studio 5000

Produced & Consumed data is one of the fastest ways to communicate that data because you can set a finite set of data in all processors that are exchanging data.

In this example video, I am setting up produced consumed data for two PLC processors using a DINT. A small amount of data to get a clear understanding of how the properly set up the communications.

Please do not skip through because you will miss very important steps.

0:00 Building our PLC programs
2:00 Setting up the processors in the I/O tree
4:40 Adding our tags for produced data in machine 1
6:21 Adding the Consumed data in machine 2
7:50 Adding produced tags in machine 2
9:10 Adding consumed data in machine 1
10:35 Downloading the machine 1 PLC program
11:05 Downloading the machine 2 PLC program
12:05 Testing the produced consumed data
14:10 Quick tip to find produced data or consumed data
16:30 Recommended videos for you

I hope it helped.

Thank you for watching the video.
