C-More Micro HMI Hardware Unboxing and Review
We will now unbox and review our C-More Micro hardware. Human-machine interfaces (HMIs) are made to display and control operations for our automation solution. Information is displayed in a graphic format. (Graphical User Interface – GUI) The HMI is usually part of the SCADA (Supervisory Control and Data Acquisition) system.
Communication from the HMI to the control is usually done through a serial (RS232 / RS485 / RS422) or Ethernet (RJ45) method with different protocols depending on the manufacturer of the control. The automation control device is not limited to a PLC. (Programmable Logic Controller) You can communicate also to drives, temperature process controllers, etc. The HMI usually will include several different protocols and port configurations to maximize the amount of control product that it will be able to communicate.
We will be looking at one of the newest members of the C-More Micro Panel HMI devices from Automation Direct. This is the EA3-T4CL. This four-inch color TFT LCD screen offers great features that we will be exploring as we review this product. Let’s get started.
More information can be obtained at our website. This includes all of the links mentioned in this video.
https://accautomation.ca/c-more-micro-hmi-system-hardware
There are several reasons that we are using the EA3-T4CL C-More Micro Panel. Here are a few:
• Touch screen display
• Free downloadable programming software
• 482 x 272-pixel display (WQVGA) with up to 40 lines by 80 characters of text and graphics
• 32K colors
• 14MB memory
• Built-in USB type Micro-B programming port
• Built-in RJ45 Ethernet Port
• Built-in 15-pin serial communications port
• Built-in RJ12 serial communications port
• Built-in Alarm Control setup that activates beep, back-light flash, customized alarm banner, and red LED blinking
• 0 to 50 °C (32 to 122 °F) operating temperature range (IEC 60068-2-14)
• NEMA 4/4X, IP65 compliant when mounted correctly, indoor use only
• UL, cUL & CE agency approvals
• 2-year warranty from date of purchase
-
