Temperature dependence of Resistance of different Electrical Components

Save
3 years ago
10
Ptc ntc electrical components Makrolon temperature coefficient thermostat alloys

Objective:

To find the resistance of electrical components at different temperature values.

Related Concept:

Carbon film resistor , metallic film resistor , PTC , NTC , charge carrier generation , free path.

Apparatus:

1. Immersion probe
2. Immersion thermostat TC10
3. Accessory set for TC10
4. Bath for thermostat , Makrolon
5. Connecting cable , 4mm plug , 32A , blue , l = 50cm
6. Connecting cable , 4mm plug , 32A , red , l = 75cm
7. Connecting cable , 4mm plug , 32A , blue , l = 75cm
