Display Specs:
Panel Size: 21.5inch
Resolution: 1920X1080
Aspect Ratio: 16:9
Brightness: 1500nits
Backlight: White LED
Backlight Life(Hrs): 50000(Min.)
Contrast: 1000:1
Color Depth: 16.7M

Input:
3G/HD/SD-SDI: BNC× 2
SD
480i60
576i50
HD
720p24/23.98 p25 p30/29.97 p50 p60/59.94
1080sf24/23.98 sf25 sf29.97 sf30
1080i60/59.94 i50 i60/59.94
1080p24/23.98 p25 p30/29.97 p50 p60/59.94
3G
1080i50 i60/59.94
1080p24/23.98 p25 p30/29.97 p50 p60/59.94
3G-2K
1080sf24/23.98 sf25 sf29.97 sf30
1080p24/23.98 p25 p30/29.97 p48/47.95 p50 p60/59.94

HDMI: HDMI×1
720p50 p60/59.94
1080sf24/23.98 sf25 sf29.97 sf30
1080i50 i60/59.94
1080p24/23.98 p25 p30/29.97

Color Management:
Camera LUT (30 SDR&14 HDR LUTs, Detailed in User Manual)
Load LUT File (USB, Up to 16 User LUTs can be Stored)
Gamma (PQ, HLG)
Color Temperature (D55, D61, D65, D93, DCI, User1, User2)
Color Space (ITU709, EBU, SMPTE-C, Native, P3, ITU2020)

Audio Tools:
Audio Source (Embedded/External/No Signal)
Speak Out L/R (Select Channels for Left or Right Speaker, Embedded Signal Only)
Meter Display

Frame Tools:
Aspect (16:9/4:3/15:9/14:9/13:9/1.85:1/2.35:1/Variable(Value 1.00-3.00 Adjustable)/Off)
Center Marker (On/Off)
Area Marker (80%/85%/88%/90%/93%/95%)
Crosshatch (On/Off)
Marker Fit (On: Area Marker Based on the Current Input/Off: Area Marker Based on the Aspect Marker)
Marker Level (Marker Line Luminance 50%/75%/100%)
Marker Mat (Darkness of the Outside Area of Aspect Marker Off/Half/Black)

Scope Tools:
Waveform
Vectorscope
Histogram

Exposure Tools:
False Color (Spectrum/SONY Slog3/SONY Slog2/ARRI LogC/Canon Clog2/Canon Clog3/Panasonic Vlog/RED RedLogFilm/RED RL3G10/BMD/BMD 4K/ARRI Rec709/SONY LC709A/SONY LC709/Panasonic V709/RED G3 and RED G4)
Zebra (Level 1-100 Adjustable)

Focus Tools:
Focus Assist (Red/Green/Blue/Mono; Sensitivity Value 0-100 Adjustable)
Peaking ( Level 1-16 adjustable)

Other Tools:
Anamorphic (2.38/Off)
