Including the Yale Z-Wave Door Lock to the Lyric Controller
In this video, Michael from Alarm Grid shows you how to pair a Yale Z-Wave Door Lock with a Honeywell Lyric Alarm System. Pairing a Yale Lock is something you will want to do if you are trying to control the lock locally from the panel or remotely from Total Connect 2.0. The pairing process is very simple, and you do not need to perform an exclusion process first, which is normally done before pairing for most Z-Wave devices.
In order to complete the inclusion process, you will need to know the Master Pin for the Yale Lock. The Master Pin is set when you first set up the lock. The pairing process is completed by activating the inclusion function for the Yale Z-Wave Lock, while the Lyric System is in its Z-Wave inclusion mode. This mode can be easily accessed from within the system's Automation Tools Menu. Also keep in mind that you should have the lock in close proximity to the Lyric System before attempting to include.
As for activating the inclusion function for the Yale Z-Wave Lock, it is actually quite simple. You simply enter the Master Pin, followed by the Gear Icon in the lower-right corner, and then the [7] key. The digit 1 should be displayed to indicate that the lock has entered its inclusion mode. If you see a 3 instead of a 1, then you are actually in the lock's exclusion mode, and you should first exclude, or clear, it from the network. But if you do indeed see a 1, then you can press the Gear Icon instead to confirm.
If everything was performed correctly, you should then see a message on the Lyric stating that a new device has been included. Please note that it will typically take a few minutes before the Lock is fully paired and it is usable on the Lyric System.
-
