70W Explosion Proof LED Light Fixture - 6000 Lumens - C1D1&2 - Gooseneck Mount - Wiring Hub

https://www.larsonelectronics.com/product/146998/70w-explosion-proof-led-light-fixture-6000-lumens-c1d1-2-gooseneck-mount-wiring-hubShow more

The EPL-LP-70W-LED-HDGN-M-100-EPP from Larson Electronics is a Low Profile LED Light Fixture that provides operators with a powerful and energy efficient alternative to traditional hazardous location luminaries. LED technology and compact design makes this lamp an excellent replacement upgrade option for bulky and high maintenance cost older fixtures. This unit is equipped with a rear access wiring hub and terminal strips as well as a versatile gooseneck mounting system equipped with a magnetic mounting plate that features four powerful 200 lb magnets which provide reliable mounting and positioning versatility in a wide variety of situations.

This Class I Divisions 1 & 2, Class II Divisions 1 & 2 explosion proof light fixture provides 6,000 lumens of high quality light while drawing only 70 watts. It is available in 360° and 180° beam spreads. The copper free aluminum alloy body is powder coated for added durability and an attractive aesthetic appearance. A special heat dissipating design in conjunction with advanced LED driver technology helps this fixture achieve an excellent 100,000 hour rated lifespan with 70% lumen retention. Light weight and a low profile make this unit an attractive alternative to larger and heavier older fixtures and requires less hardware to install.

This light is universal-voltage capable and can be operated with 100-277 VAC, 50/60Hz without any need for a ballast or transformer. The aluminum body and LED lamp assembly gives this light excellent durability and resistance to vibration and impacts. The housing is specially designed to dissipate heat, which increases the efficiency and lifespan of the LED emitters. This high output LED lamp produces 6,000 lumens with a color temperature of 5000K and a color rendering index of 70, which means this lamp render colors and details much more accurately than high pressure sodium or mercury vapor luminaries.

LED Benefits: Unlike gas burning and arc type lamps that have glass bulbs, LEDs have no filaments or fragile housings to break during operation and/or transportation. Instead of heating a small filament or using a combination of gases to produce light, light emitting diodes (LEDs) use semi-conductive materials that illuminate when electric current is applied, providing instant illumination with no warm up or cool down time before re-striking. Because there is no warm up period, this light can be cycled on and off with no reduction in lamp life.

LED lights run at significantly cooler temperatures than traditional metal halide and high pressure sodium lights and contain no harmful gases, vapors, or mercury, making them both safer and more energy efficient. No extra energy is wasted in cooling enclosed work areas due to external heat emissions from bulb type lights, and the operator risks associated with traditional lighting methods, such as accidental burns and exposure to hazardous substances contained in the glass bulbs, are eliminated. In addition, LEDs are also safer for the environment as they are 100% recyclable, which eliminates the need for costly special disposal services required with traditional gas burning and arc type lamps.

Note on Beam Spread: The 360° beam spread is the standard directional output and typical for flood lights. The 180° shines in only one direction. This is good for down lighting, wall packs and for not blinding oncoming traffic or pedestrians.

Mounting: The EPL-LP-70W-LED-HDGN-M-100-EPP features a magnetic gooseneck mounting system that offers operators a high degree of versatility and adjustment. This mounting system features four pivot points that offer maximum flexibility and precision in adjusting and positioning the light head. This allows operators to dial in the ideal position for precise coverage of their work area with the infrared LED light as required. Two sets of double ball joints allow for swivel movement and are adjusted by loosening/tightening aluminum T-handles on the gooseneck mount and thumbscrews on the trunnion bracket that connects the light head to the mounting bracket. A magnetic base plate that features four 200lb magnets offers further versatility and allows operators to securely attach the light to magnetic surfaces. This allows for temporary mounting for inspection operations on the job site as well as providing a mounting method for instances where drilling holes isn`t desired or where a quick and fast install is needed.
