Name: Boss DD-3 Delay Pedal - Troubleshooting and Repair (#001)
Uploaded: 2021-06-29T04:12:17+00:00
Duration: 10 min 54 s
Description: Troubleshooting and repairing a Boss DD-3 Delay Pedal. This is an earlier version which appears to share the same schematic as the DD-2 and has all through-hole components. Symptom: No sound at the ma

2 years ago

523

Boss DD-3 DD-3 DD-2 Delay Pedal guitar pedal guitar electronics

Troubleshooting and repairing a Boss DD-3 Delay Pedal. This is an earlier version which appears to share the same schematic as the DD-2 and has all through-hole components.

Symptom: No sound at the main output.

Clarification: The 400mV note at 1:56 is peak to peak voltage.
