Name: Trying out a small OLED module from Amazon: CenryKay 12864.
Uploaded: 2021-04-02T16:40:54+00:00
Duration: 4 min 34 s
Description: Testing these serial OLED modules in all three of their serial modes. I2C, 3 wire SPI and 4 wire SPI. Showing which resistors to put in and which to remove to switch to the different modes. Link to MP

3 years ago

serial oled display hobby oled display electronic project

Testing these serial OLED modules in all three of their serial modes. I2C, 3 wire SPI and 4 wire SPI. Showing which resistors to put in and which to remove to switch to the different modes.

Link to MPLAB X dsPIC33CK256MP206 project to interface to these modules:

https://github.com/mlplel/SSD1306Serial.X
