Wiring InkBird ITC-106RL PID
3 years ago
23
This is a quick video about how I wired my InkBird ITC-106RL PID to directly control a fan without the need of a SSR. I'm not saying this is the right way or the way that you should do it. I'm just showing what worked for me.
I will be using this to control the temperature in my smoker by stoking the fire when it drops below a certain level, but it could also be wired to cool something down by moving the negative lead of the fan do a different connection point as I mention in the video.
I hope this helps as the instructions that came with the PID were not very clear to me as to how to accomplish this.
