How to Identify & Test Briggs & Stratton Alternators (Single Circut, Dual Circuit, Regulated, etc.)

In this video, I break down the main types of Briggs & Stratton alternators — 10/16Amp, Dual‑Circuit, unregulated vs regulated units— show you how to identify yours, and how to test each one using a digital multimeter.

Timestamps:
00:00 Intro
0:11 Alternator types overview
1:02 Wiring & output specs for each type
1:47 DC + AC lighting circuit vs DC output only
2:49 Why I'm replacing the alternator on the V-Twin
3:42 How to test the Dual Circuit Unregulated alternator /stator
5:45 Why I'm replacing the alternator on the Intek Single
6:02 How to test the 10/16amp Regulated alternator /stator
7:39 Conclusion

🛠️ Tools Needed:
• Digital multimeter (AC/DC)

👍 LIKE this video if it helped, and FOLLOW for more small engine repair tutorials!

💬 Leave a comment if you successfully tested your Briggs charging system!
