Balance Charging Module IP2326 2S 3S Lithium ion/poly Battery 8V 12V balance Charger

Balance Charging Module IP2326 2S 3S Lithium ion/poly Battery 8V 12V balance Charger

এই মডিউলটি এখান থেকে কিনতে পারবেনঃ দারাজঃ https://www.daraz.com.bd//products/i364656307-s1812765191.html?spm=a2o42.cart.0.0.776c2829KYZBcN&urlFlag=true&tradePath=%2CcartPriceDrop%2Ccart

লোকাল শপঃ https://rebrand.ly/IP2326EBD

ভোল্ট / অ্যাম্প / ওয়াট মিটারঃ https://s.click.aliexpress.com/e/_ooSY44Q

অন্যান্য প্রোডাক্ট কিনতে পারেনঃ https://rebrand.ly/VoltH-BD

2S 3S Type-C USB BMS 15W 8.4V 12.6V 1.5A Lithium Battery Charging Boost Module With Balanced Support Fast Charge With Indicator

দেশে এলো নতুন একটি মডিউল যা দিয়ে পুরাতন ল্যাপটপের ব্যাটারিকে ব্যালেন্স চার্জ করা সম্ভব।
এতে করে কিছুদিন পর ব্যাটারি নষ্ট হওয়ার সম্ভাবনা আর থাকেনা।

________________________________________________________________________
About @BanglaGECS

Facebook: https://www.facebook.com/bangla.gecs.official/
Twitter: https://x.com/BanglaGECS
Instagram : https://www.instagram.com/banglagecs/
Contact (Business) : sabbirm340@gmail.com
Message (Facebook) : m.me/sabbirgecs
Tiktok: https://www.tiktok.com/@bangla_gecs
Rumble: https://rumble.com/c/c-5806512
_________________________________________________________________________

Timeline:
0:00 Intro
1:15 Port and Connections
2:07 LED Indication
2:31 2S Lithium ion Battery Over-Charging
3:42 2S Lithium Ion Battery Balance Charging
4:42 Constant Efficiency Smart Feature
5:18 Trickle Charging Battery Balancing
6:47 ONE MONTH TEST!
7:32 Bad Sides
8:32 Solution for Wire Burning
8:47 2S Lithium ion Battery Charging
9:24 Over-Charging 8V battery to 12V
9:58 Summary
_________________________________________________________________________
● Product name: IP2326 two/three series lithium battery charging module

● Input voltage: lithium battery voltage [QC fast charge voltage adaptive]

. Full voltage: two strings 8.4V/three strings 12.6V [adjustable Settings]

Constant current: 1.4A can be set

● Support the setting of charging current, charging voltage, input undervoltage threshold, input overvoltage threshold, charging timeout threshold and other parameters through the external resistor

● With output overcurrent, overvoltage, short circuit protection, chip overtemperature, NTC temperature protection and other functions

● Integrated two series of charge balancing circuit, charge status LED indicator

● Module interface: Type-C, welding hole

● Size: 31.2mm*18.1mm (length * width)

3.7V Lithium Battery 5V Charging 2 Series 3 Series lithium Battery Booster Charging Board Module Supports QC Fast Charging

Support QC protocol 2/3 series lithium charging module

Support QC fast charging

15W synchronous switch boost charging

The boost charging efficiency is 94%

2 or 3 strings of lithium batteries can be set to charge

2 series with balanced charging

The charging current is adjustable

Input overvoltage and undervoltage protection

Adjustable charge timeout protection

Output over current, over voltage, short circuit protection

The module is suitable for two or three strings of 3.7V lithium batteries, through the short-circuit setting, the default is 2 strings, when two strings are used, the battery balancing function of the module can be used, this is very practical, input the available type-c port and welding wire,type-c port is connected to the fast charging source, automatically adjust the charging voltage, improve efficiency, if the welding wire input, The input voltage should be less than the battery voltage, and the module can only work in the boost state.

Note: 1 Do not connect the battery after receiving, plug in the charging cable, the red light will be on, and the blue light will blink normally. 2 Charging board is only applicable to ternary lithium battery, 3.7V reference voltage, 4.2V charging cut-off voltage. Cannot be used in lithium iron batteries.
