Jeep Cherokee XJ Diesel Post Overland Build Walkaround
Big Thanks to Ruff Stuff for the support! Below are the mods I use from them.
XJ Chassis Channel Reinforcement - https://www.ruffstuffspecialties.com/catalog/XJRAIL.html
XJ Front Frame Reinforcement Plate Kit - https://www.ruffstuffspecialties.com/catalog/R2093.html
Single Flex Lower Front Control Arm - https://www.ruffstuffspecialties.com/catalog/SFLEX-LF.html
Adjustable Front Upper Control Arm - https://www.ruffstuffspecialties.com/catalog/R2389.html
Jeep XJ RHD Ton Steering Kit - https://www.ruffstuffspecialties.com/catalog/R2237.html
Megan and I spent four months living in the jeep XJ while we traveled North into Scandinavia and in this video we recap the suspension, bodywork, bumpers, axles and structural changes of the build prior to our departure seeing how the mods performed. We also take a look at improvements made after the trip in preparation for the cold winter and future trips in 2019.
In Part 2 we recap internal modifications made to the jeep prior to the trip but mainly we focus on the vast improvements made to the internal storage drawers and cargo area as well as the gear carried in the vehicle and how its organised.
Support me on Patreon - https://www.patreon.com/WorkshopWildernessAdventures
Check out Amazon USA - https://www.amazon.com/shop/mcqbushcraft?listId=1S3Z2JAVD999B&ref=idea_share_inf
Follow me on Instagram - https://www.instagram.com/workshopwildernessadventures/
Follow me on Facebook - https://www.facebook.com/Workshop-Wilderness-Adventures-2127584970825155
Jeep Spec:
1999 Jeep Cherokee XJ 2.5TD RHD.
35x12.50r15 BFG KM3's with 15x8 3.75" backspacing (-19 offset).
Lift Front - RC 4.5" Coils and N2 Shocks (2" Coil Spacer).
Front Shock Bar Pin Eliminator.
Dana 30 High Pinion with Artec Industries Lower Control Arm Mounts with modified upper mount and modified Track Bar mount.
Front RC Control Arm Drop Bracket.
Ruff Stuff Short Arm Single Himes.
RC Extended Sway Bar Links.
Dana 30 Rock Crusher Diff Cover.
Ruff Stuff One Ton OTK Steering.
6" Lift Drop Pitman Arm.
Ruff Stuff Front and Center Frame Stiffeners.
Rear DIY Frame Stiffener and Rear Frame Tie in Kit.
6" x 2" Box Rocker replacement with Tube Slider.
Modified Factory Bumper with Side Sliders.
Rear Tow Hitch Tire Carrier that bolts into Rear Frame Tie in Kit.
Modified upper Shock Crossmember for Rear Shocks
Rear Axle Chrysler 8.25 29 Spline with modified High Clearance Shock Mounts.
Rear Shocks 6.5" Trailmasters.
Rear Leaf Springs 4.5" Trailmasters with two RC Leaf Springs from a 4.5" kit.
Rear RC Shackle Relocation Bracket.
Stainless Steel Braided Brake Lines front and back.
Warrior 9500lb Winch.
Front Bumper - https://www.ebay.co.uk/itm/Jeep-Cherokee-Xj-89-01-Front-Steel-Bumper-Winch-Off-Road/324043608951?hash=item4b72811377:g:84MAAOSwxOReH4as
-
