Toggle clamp 2b

PhenomenonPublished: March 17, 20171 views
Published: March 17, 2017

Toggle clamp 2b Toogle clamp using four bar linkage.
Green conrod and violet lever come into toggle by an extension of each other.
The clamping force is applied to the conrod.
STEP files of this video:
