NEVER BEFORE SEEN: RK and TYM T25 Hub Bearing Seal Replacement - E131
Yes. you can do it!
This has been leaking for a while on the front end of the RK25 tractor and I was putting off replacing this part that was losing oil. It wasn’t a lot but it also wasn’t good.
We go through step by step on how we replaced it and cut out some of the mistakes so you don’t fall into some of that. Timewise it took us about 2-3 hours to take apart along with remove from the tractor. Reassembly was about a half hour. Filling up the axle with new oil took probably an hour.
Here is the parts and tools list:
Tools needed for Bearing replacement
USE PARTS DIAGRAM from manual
jack/jack stands
plastic/rubber hammer
large socket for tapping in bearings - not needed for me
17mm and 14mm (12 point), 1/2”, 7/8” socket and wrench, then the one for lug nuts also
Torque wrench
Good set of snap ring pliers
couple of flat screwdrivers - or something else to help pry
grease to help new seal slide in place
teflon tape for drain plugs
loctite 277 - for finishing
Torque specs:
16-21 foot pounds for 17 (1/2” around the hub) and then 57-72 foot pounds for 3 (17mm (four attaching hub to axle).
Parts maybe: Bottom oil cap: 13154130160 cap.55
bearing seal: 13154130150
gasket O-ring: 13154130170
-
