Transformer with Built-in Panelboard, 480V-120/240V 1PH, 30 Circuits, MCB Breakers
The MPD-B2N1-TB.40AB-SE15SZ-EZ-30.CKT-M1 Transformer with Built-in Panelboard from Larson Electronics is powerful, reliable and designed with the environment in mind. Suitable for both indoor and outdoor applications, this power distribution system converts single-phase 480V AC to single-phase 120/240V AC. The MPD-B2N1-TB.40AB-SE15SZ-EZ-30.CKT-M1 is equipped with a built-in panelboard which features a primary MCB breaker (not stab-in or bolt-in breaker) and 30 circuits.
Transformer Features: With a transformer rating of 15 KVA, the MPD-B2N1-TB.40AB-SE15SZ-EZ-30.CKT-M1 is a single-phase unit with a primary voltage of 480V AC. It also provides a secondary voltage of single-phase 120/240V AC. Featuring robust construction, this unit's cores are manufactured with non-aging, cold-rolled silicon steel laminations using state of the art technology.
