china’s brand new 6x4 dump trucks & ac luxury coaches
Dump truck is mainly used for transportation of dumps, such as sand and stone.
Model ZZ3317N4667A
Color Optional Red, White, Yellow, Blue)
Driving type LHD/RHD
Engine Make: SINOTRUK
Engine model: WD615.47, 371hp, Euro 2
6-cylinder in-line with water cooling, turbo-charging and inter cooling.
Rated Power (kw/rpm): 273/2200
Maximum Torque (Nm): 1500N.m
Maximum Torque speed: 1100~1600RPM
Displacement: 9.726 L
Cabin HW76 cabin, with one sleeper (berth), Air-conditioner, MP3, safety belts, adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers, etc.
Steering ZF8118 power steering with hydraulic system.
Front Axle Heavy duty axle, 9000kgX1, drum brake.
Rear Axles Heavy duty axle,16000kgX2. Speed ration: 4.42;4.8;5.73
Wheelbase (mm) 1800+4600+1350
Front/Rear overhang (mm) 1500/1895
Wheel track (front/rear) mm 2022/1850
Minimum ground clearance (mm) 314
Approach/departure angle19/(24/47)
Braking System Service brake: dual circuit compressed air brake
Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake engine exhaust brake.
Electrical System Voltage: 24 V Generator: 1540W Starter: 24 V, 7.5 Kw
Batteries: 12V/165Ah, 2 pieces Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light.
Tire 12.00R20, radial steel tire, plus one spare tire (11 units)
Fuel tank 300L volume
Tipper box (mm) 8500X2300X1500 (30 m3)
Front lifting, strengthen model.
External dimension 11500x 2600x3450 mm
Products GENUINE PARTS,
HOWO SERIES, Dump Truck, Tractor, Cargo Truck, Mixer Truck,
Tank Truck, Special Purpose Truck, HOWO N SERIES, Dump Truck,
Tractor, Cargo Truck, Mixer Truck, Tank Truck, Special Purpose Truck,
DUMP TRUCK 6X4 is mainly used for transportation of dumps, such as sand and stone.
Color Optional Red, White, Yellow, Blue) Driving type LHD/RHD
Engine Make Engine model: WD615.47, 371hp, Euro 2
6-cylinder in-line with water cooling, turbo-charging and inter cooling.
Rated Power (kw/rpm): 273/2200 Maximum Torque (Nm): 1500N.m
Maximum Torque speed: 1100~1600RPM
Displacement: 9.726 L
Cabin HW76 cabin, with one sleeper Air-conditioner, MP3, safety belts, adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers, etc.
Braking System Service brake dual circuit compressed air brake
Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake engine exhaust brake.
Electrical System Voltage: 24 V Generator 1540W Starter 24 V, 7.5 Kw
Batteries 12V/165Ah, 2 pieces Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light.
Dump Truck, Tractor, Cargo Truck, Mixer Truck,
Tank Truck, Special Purpose Dump Truck, Tractor, Cargo Truck, Mixer Truck, Tank Truck, Special Purpose Truck,
Virgo Trading Inc,
Ittehad commercial Dha-6 Karachi Pakistan
E-mail:- virgotradinginc@gmail.com
Skype: - muhammud.iqbal
Handy: - +923322343218
Whatsapp:- +923322343218
https://bit.ly/3IQNr6F
https://www.facebook.com/profile.php?id=100011762014198
-
