In Part 4 of the Electric brewing series we explore a RIMS system and Diagram. RIMS Brewing is a good option for someone who already has a 2 -3 vessel system and wants to convert over it over to an electric brewery. Rims brewing systems have some flexibility to them and can be used in conjunction with propane fired boil kettles. Please fell free to ask any questions and let us know what you want to see next. Link to the diagram: http://www.homebrewtalk.com/showthread.php?t=597915

ALL PRICES AS OF 2/11/17

PANEL PARTS LIST
----------------------------------------------------------------
Enclosure with (60Amp)heatsink ($71.50)
http://www.auberins.com/index.php?main_page=product_info&cPath=34&products_id=384

NO BUZZER OPTION - PID DSPR120 X2 ($46.95)
http://www.auberins.com/index.php?main_page=product_info&products_id=560:81308ff89d421bcbc9a3f8d0470abc35

W/ Buzzer option - PID DSPR300 ($58.95)
http://www.auberins.com/index.php?main_page=product_info&cPath=53&products_id=560

Buzzer ($7.86)
http://www.auberins.com/index.php?main_page=product_info&cPath=7_33&products_id=215

RTD probe W/XLR connector X2 (weldless) 8' cable ($48.95)
http://www.auberins.com/index.php?main_page=product_info&products_id=84:a01e24fe169f49c0059bfe4f6a9922bf

Element indicator light, 240V voltage option X3 ($3.45)
http://www.auberins.com/index.php?main_page=product_info&cPath=7_33&products_id=248

40 Amp SSR MGR-1D4840 X2 ($15.50)
http://www.auberins.com/index.php?main_page=product_info&products_id=30

Wire Pack 50 ft/5colors ($8.99)
https://www.brewhardware.com/product_p/wirepack50.htm

Connector pack (for connections in panel) ($4.49)
https://www.amazon.com/Insulated-Electrical-Terminal-Connectors-Terminals/dp/B01H2GTYCO/ref=sr_1_2?ie=UTF8&qid=1483880307&sr=8-2&keywords=fork+connector+assortment

Buss fuse holder (5 needed) ($2.28 Ea.)
http://www.homedepot.com/p/30-Amp-Glass-Tube-Fuse-Fuseholder-12-BP-HMK-RP/203298931

PID PROTECTION 1 amp buss fuses ($1.68)
https://www.lowes.com/pd/Cooper-Bussmann-5-Pack-1-Amp-Fast-Acting-Electronic-Fuse/50193539?cm_mmc=SCE_PLA-_-RoughPlumbingElectrical-_-Switchgear-_-50193539:Cooper_Bussmann&CAWELAID=&kpid=50193539&CAGPSPN=pla&store_code=711&k_clickID=268e6966-db76-408e-9ef6-e49235e65683

PUMP PROTECTION 10 amp Buss Fuses $(1.94)
http://www.homedepot.com/p/Cooper-Bussmann-AGC-Series-10-Amp-Silver-Fast-Act-Electronic-Fuses-5-Pack-BP-AGC-10/100200559

Pump Switch [Illuminated]
(PUSHBUTTON STYLE) ($11.98)
http://www.auberins.com/index.php?main_page=product_info&cPath=7_32&products_id=223
(ROTATING STYLE) [Illuminated] ($13.98)
http://www.auberins.com/index.php?main_page=product_info&cPath=7_32&products_id=349
